ARECA Tri-mode RAID card 16-port (2x SFF-8654) 8GB DDR4, PCIe4.0 x8 Card, LP, ARC-1886-16I

Product Highlights

? Support up to 8GB DDR4-2666 cache

? SFF-9402 compliant connector pin-out

? Support read/write cache allocation by policy

? Support up to 24 NVMe drives using PCIe switch

? Redundant flash image for adapter availability

? UBM, SES2, SMP and SGPIO enclosure management

? Support up to (512) 12Gb/s SAS, SATA or SSD drives using SAS expanders

? Support optional cache backup module (CBM) protection using SuperCap

? Tri-mode interface at each drive ports-12Gb/s SAS/SATA/ Gen 4.0 PCIe (NVMe)

? Controller level hardware encryption and self-encryption drive management

? Support RAID 1 - Multi Mirroring and Mirrored Pass-Through Disk

? Multiple RAID 0 and RAID 10 (1E) support (RAID 00 and RAID100)

? Broad operating support including Windows, Linux, FreeBSD, macOS and VMware

8/16 Ports PCIe Gen 4.0 Tri-Mode RAID Adapters

The new fourth generation ARC-1886 family offers advanced technology for increased performance and improved enterprise data protection. They were designed with 1.6 GHz dual core ROC processor, DDR4-2666 memory and PCIe 4.0 interface for the most performance-hungry database and IT applications. Based on the ARM A15 PCIe 4.0 x8 to SAS/SATA/PCIe RAID on Chip (ROC) controller, the ARC-1886 series RAID adapters can offer both PCIe Gen 4.0 host and 12Gb/s SAS/SATA/PCIe (NVMe) tri-mode storage interfaces.


ARC-1886 Series
