ARECA 8-port 6Gb/s SATA PCIe 2.0 x4, RAID 0/1/1E/3/5/6/10/30/50/60/Single Disk/JBOD, 512MB Cache, 2x SFF-8087,LP, ARC-1203-8I

ARC-1203
(4/8-Port PCIe x4 to SATA RAID Adapter)

ARC-1203 series internal PCIe 2.0 host RAID controllers are the cost-effectivesolutions for connecting 4/8 6Gb/s SATA peripherial devices. Areca’s ARC-1203 series entry-level RAID controllers cover the spectrum of wild range storage requirements for cost-sensitive applications that require robust data protection. The 4/8 port configurations are aimed at high-availability and capacity oriented applications, such as security systems, surveillance, multimedia content generation, large-volume data capturing, mail servers and entry-level database systems.

PCIe x4 6Gb/s SATA RAID Controller
Model Name
ARC-1203-4I

ARC-1203-8I
I/O Processor
ARM_based 1066MHz storage I/O processor
Host Bus Type
PCIe 2.0 x 4 Lanes
RAID Level Support
0, 1, 1E, 3, 5, 6, 10, 30, 50, 60, Single Disk, and JBOD
On-Board Cache
512MB on-board DDR3-1066 SDRAM with ECC protection
Driver Connector
1*SFF-8087

2*SFF-8087
Driver Support
4*SATA lll

8*SATA lll
Management Port
In-Band: PCIe / Out-of-Band: LCD, and LAN Port
Enclosure Ready
Individual Faulty Header, SGPIO, and Serial bus
Form Factor (H x L)
Low Profile: 64.4 x 168 mm

For the products photo link: http://www.areca.com.tw/support/photo_gallery.htm

Architecture

ARM_based 1066MHz storage I/O processor
512MB on-board DDR3-1066 SDRAM with ECC
